Catalogue · Instrument
Veterinary analysers and laboratory instruments
Everything the assays run on. Chairside: palm-sized isothermal docks and multi-dock bench units. Laboratory: real-time PCR analysers from 16 to 96 wells, thermal cyclers, automated magnetic-bead extractors from 4 to 96 samples, plus the spectrophotometer, grinder, dry bath, gel imager and pipettes that complete a molecular bench.
- Assays
- 22in this line
- Species
- 1All species
- Method
- 3 methodsLaboratory, Molecular POCT, Point of care
- Disease groups
- 7Immunoassay reader, Laboratory support, Nucleic acid extraction…
All 22 instrument assays
Every item we can quote today in this line, with catalogue number, species, specimen, pack size and read time. Click "Filter the catalogue" above to search, sort, export to CSV or open any item.
| Cat. no. | Assay | Species | Specimen | Pack | Read |
|---|---|---|---|---|---|
| INS-PM003 | MiniDock Ultra portable molecular analyser PM003 Ultra | All species | 240 g · cold-chain-free reagent · up to 6 pathogens per cartridge · barcode scanner · Wi-Fi · LIS | 1 unit | ~30 min |
| INS-PM008 | Dock Pro 8 eight-channel molecular analyser PM008P | All species | 8 independent channels · benchtop, stackable · 7-inch touchscreen · optional printer · LIS | 1 unit | ~30 min |
| INS-FIA | Veterinary immunofluorescence quantitative analyser VET-YC01 / YC02 | All species | LCD touchscreen · internal thermal printer · HIS/LIS · store and operate 4–30 °C | 1 unit | 3–15 min |
| INS-URINE | Veterinary urine chemical analyser HY-611 VET | All species | 11 parameters: WBC, NIT, URO, PRO, pH, BLD, SG, BIL, GLU, KET, ascorbic acid · 200 samples/hour | 1 unit | ~60 s |
| INS-BFEX-4 | Automated nucleic acid extractor, 4 samples BFEX-4E / 4X | All species | Magnetic-bead extraction · 4 samples per run · compact bench footprint · rotary extraction optional · suits field sampling | 1 unit | As fast as 8 minutes per run |
| INS-BFEX-16 | Automated nucleic acid extractor, 16 samples BFEX-16E / 16X | All species | Magnetic-bead extraction · 16 samples per run · compact size · rotary extraction optional | 1 unit | As fast as 8 minutes per run |
| INS-BFEX-32 | Automated nucleic acid extractor, 32 samples BFEX-32E | All species | Magnetic-bead extraction · 32 samples per run · high throughput · compatible with the full extraction-kit range | 1 unit | As fast as 8 minutes per run |
| INS-BFEX-24 | Automated nucleic acid extractor, 24 samples, large volume BFEX-24E | All species | Magnetic-bead extraction · 24 samples per run · large-volume wells for efficient recovery of free nucleic acids | 1 unit | As fast as 8 minutes per run |
| INS-BFEX-96E | Automated nucleic acid extractor, 96 samples BFEX-96E | All species | Magnetic-bead extraction · 96 samples per run · ultra-high throughput | 1 unit | Fastest processing 8 minutes |
| INS-BFEX-96 | Automated nucleic acid extractor, 96 samples, high-mix BFEX-96 | All species | Magnetic-bead extraction · 96 samples per run · ultra-high throughput · high mixing and extraction efficiency | 1 unit | Fastest processing 8 minutes |
| INS-FC96GE | Thermal cycler, gradient, rotatable screen FC-96GE | All species | 96-well · electrically controlled hot lid · 75° rotatable screen · ramp rate 5.5 °C/s · uniformity ±0.2 °C · accuracy ±0.1 °C · gradient 1–36 °C | 1 unit | Per protocol |
| INS-FC96B | Thermal cycler, compact FC-96B | All species | 96-well · compact design · ramp rate 5 °C/s · uniformity ±0.2 °C · accuracy ±0.1 °C · gradient 1–36 °C | 1 unit | Per protocol |
| INS-FC96BE | Thermal cycler, routine FC-96BE | All species | 96-well · cost-effective routine amplification · ramp rate 4 °C/s · uniformity ±0.3 °C · accuracy ±0.1 °C · gradient 1–36 °C | 1 unit | Per protocol |
| INS-BFQP1650 | Real-time fluorescent PCR analyser, 16-well BFQP-1650 | All species | 16-well · 5-colour fluorescence · compact design · ramp rate 6 °C/s · uniformity ±0.2 °C · accuracy ±0.1 °C | 1 unit | Per protocol · single-channel scan under 1 s |
| INS-BFQP4850 | Real-time fluorescent PCR analyser, 48-well BFQP-4850 | All species | 48-well · 5-colour · electrically controlled lid · PMT detector · bottom scanning, no optical path difference · ramp rate 5 °C/s · uniformity ±0.2 °C | 1 unit | Per protocol · single-channel scan under 1 s |
| INS-BFQP9650 | Real-time fluorescent PCR analyser, 96-well BFQP-9650 | All species | 96-well · 5-colour · electrically controlled lid · PMT detector · bottom scanning, no optical path difference · ramp rate 6 °C/s · uniformity ±0.2 °C · accuracy ±0.1 °C | 1 unit | Per protocol · single-channel scan under 1 s |
| INS-BFMUV | Ultra-micro spectrophotometer BFMUV-3100 / 3100F | All species | Micro-volume nucleic-acid and protein quantification · 3100F adds fluorescence | 1 unit | Per sample |
| INS-BFEP300 | Electrophoresis power supply BFEP-300 | All species | Bench power supply for agarose and polyacrylamide gels | 1 unit | Continuous |
| INS-BFDB | Dry bath incubator BFDB-N1 | All species | Block heating for tubes · digital temperature and time control | 1 unit | Per protocol |
| INS-BFYM48 | Tissue grinder, 48-position BFYM-48 | All species | Bead-mill homogeniser for tissue, faecal and environmental samples ahead of extraction | 1 unit | Per batch |
| INS-BFGI500 | Gel imaging system BFGI-500 | All species | Cabinet imager for stained gels · documentation and analysis software | 1 unit | Per gel |
| INS-BF031 | Pipettor series BF031 series | All species | Single- and multi-channel adjustable pipettes | 1 unit | — |
Questions distributors ask about this line
Are the analysers sold separately from the reagents?
They are quoted together. A distributor usually places the analysers with clinics and then supplies the consumables, so the quotation covers both.
What does a clinic need to run the isothermal line?
One dock, the test cards, and a swab. The dock weighs about 240 grams, reads up to six pathogens per card and connects to the clinic system.
Is training provided?
Yes. Set-up and operating guidance is supplied with the first order, and the evidence page lists the validation documents your clinical team will ask for.
Price this line for your market.
Send the assay numbers or the species you serve. You get specifications, certificates, minimum order quantities and lead times, usually within two working days.
